sonar ANATEC REVOLUTION 2010 RAZA 300m

Sonar & Radio

Depth Capability: 0.3~30m

Wireless Operating Range: Max 300m

Sonar Frequency: 455KHz

Sonar Beam Angle: 80deg @-10dB

Radio Frequency: 433.9MHz

Sonar Alarms: Fish / Shallow / Low Battery

Monitor and Display Real-time Voltage of

Bait boat Battery

3. Technical and casing

Sensor Cable Length: 1.2m

Sonar unit size: 153 x110 x 44mm

Portable Case Size: 262 x 150 x 98mm

Operational Temperature: -10° C ~ 50° C

Water & Air Temp. Included

IPX7 Level Waterproof Casing Design

4. Power

Control box Power Supply: 6~12V
